IDEC OpenNet series

24: REMOTE I/O SYSTEM
OPENNET CONTROLLER USER’S MANUAL 24-27
0C94hex to 0C97hex (RB FAIL)
0C98hex to 0C9Bhex (RB FAIL) or 0D98hex to 0D9Bhex (LB FAIL)
0D9Chex to 0D9Fhex (LB FAIL)
0CC0hex to 0CC3hex (RB FAIL) or 0DC0hex to 0DC3hex (LB FAIL)
0CC4hex to 0CC7hex (RB FAIL) or 0DC4hex to 0DC7hex (LB FAIL)
0CC8hex to 0CCBhex (RB FAIL) or 0DC8hex to 0DCBhex (LB FAIL)
Meaning
An INTERBUS device with the ID code of a local bus device was found at the outgoing remote bus
interface (OUT1) of the specified INTERBUS device.
Add_Error_Info Error location (Segment . Position).
Meaning
The INTERBUS device connected to the outgoing remote bus interface (OUT1) of the specified INTER-
BUS device has an invalid ID code.
Add_Error_Info Error location (Segment . Position).
Meaning
The local bus connected directly to the controller board consists of more devices than have been
entered in the active configuration.
Add_Error_Info Error location (Segment . Position).
Meaning Multiple errors at the outgoing bus interface (OUT2) of the specified INTERBUS device.
Cause
– INTERBUS cable connected to the outgoing bus interface (OUT2) without any further INTERBUS
device.
– A local/remote bus cable is defective that belongs to the local/remote bus of the specified INTER-
BUS device.
– Defective INTERBUS device connected to the local/remote bus of the specified INTERBUS device.
– Failure of the supply voltage (communication voltage U
L
) for the module electronics made available
by the BK module.
– Failure of the supply voltage (U
L
) for the BK module.
Remedy Check this local/remote bus.
Add_Error_Info Error location (Segment . Position).
Meaning Multiple timeout at the outgoing bus interface (OUT2) of the specified INTERBUS device.
Cause
– Defective local/remote bus cable that belongs to the local/remote bus of the specified device.
– Defective INTERBUS device connected to the local/remote bus of the specified INTERBUS device.
– Failure of the supply voltage (communication voltage U
L
) for the module electronics made available
by the BK module.
– Failure of the supply voltage (U
L
) for the BK module.
Remedy Check this local/remote bus.
Add_Error_Info Error location (Segment . Position).
Meaning
Unexpected devices were found at the outgoing bus interface (OUT2) of the specified INTERBUS
device.
Cause
– INTERBUS device connected without an entry in the active configuration.
– INTERBUS cable connected without any further INTERBUS devices.
Add_Error_Info Error location (Segment . Position).
