24: REMOTE I/O SYSTEM
24-28 OPENNET CONTROLLER USER’S MANUAL
0CCChex to 0CCFhex (RB FAIL) or 0DCChex to 0DCFhex (LB FAIL)
0CD0hex to 0CD3hex (RB FAIL) or 0DD0hex to 0DD3hex (LB FAIL)
0CD4hex to 0CD7hex (RB FAIL) or 0DD4hex to 0DD7hex (LB FAIL)
0CD8hex to 0CDBhex (RB FAIL) or 0DD8hex to 0DDBhex (LB FAIL)
0CDChex to 0CDFhex (RB FAIL) or 0DDChex to 0DDFhex (LB FAIL)
The error codes described above are excerpts from:
INTERBUS User Manual
Generation 4 Controller Boards as of Firmware 4.12
Designation: IBS SYS FW G4 UM E
Order No. 27 45 18 5
Section 3 Error Codes
Meaning Only ID cycles but no data cycles can be run.
Cause
– Interrupted data register of the INTERBUS device connected to OUT2.
– The number of data registers of the INTERBUS device connected to the outgoing interface (OUT2) of
the specified INTERBUS device is not identical with the length code entered in the configuration
frame.
Remedy
Replace the INTERBUS device which is connected to the outgoing bus interface (OUT2) of the speci-
fied INTERBUS device or adapt in the configuration frame the entry to the length code.
Add_Error_Info Error location (Segment . Position).
Meaning
After the outgoing bus interface (OUT2) of the specified INTERBUS device was opened, further
devices in addition to a BK module were included in a data ring.
Cause
The INTERBUS device connected to the outgoing bus interface (OUT2) of the specified INTERBUS
device carried out a voltage reset or is defective.
Remedy
– Check this INTERBUS device.
– Check the supply voltage of this INTERBUS device whether it conforms to the rated value and
whether the permissible AC voltage portion is exceeded. Refer to the relevant data sheet for the val-
ues.
– Check the BK module’s power supply unit for an overload condition. Refer to the relevant data
sheets for the maximum permissible output current of the BK module and for the typical current
consumption of the connected local bus devices.
Add_Error_Info Error location (Segment . Position).
Meaning Error in the 8-wire local bus connected to the specified INTERBUS device.
Cause
– Defective local bus cable that belongs to the local bus of the specified device.
– Defective INTERBUS device connected to the local bus of the specified INTERBUS device.
– Failure of the supply voltage (communication voltage U
L
) for the module electronics made available
by the BK module.
Remedy Check this local bus.
Add_Error_Info Error location (Segment . Position).
Meaning
The local bus connected to the specified bus terminal module consists of more local bus devices than
were entered in the active configuration.
Add_Error_Info Error location (Segment . Position).
Meaning
The INTERBUS device connected to the outgoing bus interface (OUT2) of the specified INTERBUS
device has an invalid ID code.
Add_Error_Info Error location (Segment . Position).
