27: TROUBLESHOOTING
27-14 OPENNET CONTROLLER USER’S MANUAL
Troubleshooting Diagram 7
Does the monitored
input turn on and off?
NO
YES
NO
YES
YES
Call IDEC for assistance.
Monitor the designated stop or
reset input using WindLDR on a
computer.
NO
Is the designated stop
or reset input on?
Is M8000 off?
Turn on the designated input.
The input circuit in the input
module is damaged.
Replace the input module.
Is stop or
reset input designated in
the WindLDR Function Area
Settings?
Monitor the start control special
internal relay M8000 using
WindLDR on a computer.
YES
Turn off the start control special
internal relay M8000 using
WindLDR on a computer.
NO
Cannot stop or reset operation.
Note: To monitor M8000, from the WindLDR menu bar,
select O
nline > Monitor and Online > Direct Monitor. Enter
M8000 in the Direct Monitor Dialog.
Note: To turn off M8000, from the WindLDR menu bar, select
O
nline > Monitor and Online > Direct Set/Reset. Enter
M8000 in the Direct Set/Reset Dialog. Press Reset and OK.
