WSB-9152 PICMG 1.0 SBC
Page 6
Specification WSB-9152
System Chipset
Northbridge: Intel® 915GME
Southbridge: Intel® ICH6-M
Memory
Two 240-pin DIMM sockets support two dual channel
400 MHz or 500 MHz DDR2 DIMMS with a maximum capacity
of 1 GB each
Display
VGA: Integrated in the Intel® 915GME
LVDS: 18-bit dual channel LVDS
DVI: Chrontel 7307C (WSB-9152DVI and WSB-9152SDVI)
BIOS
AMI BIOS
Ethernet
Dual Broadcom BCM5787M PCIe GbE ports
COM
Two RS-232 serial ports
USB
Seven USB 2.0 devices supported
IDE
Two 40-pin IDE connectors
Floppy Disk Drive
One 34-pin FDD connector
SATA
Two 1.5 Gb/s SATA drives supported
Two 3.0 Gb/s SATA II drives (WSB-9152S and
WSB-9152SDVI)
Keyboard/mouse
One 5-pin connector for mouse or keyboard
One external PS/2 connector for mouse or keyboard
Infrared
One infrared connector
Watchdog Timer
Software programmable 1-255 sec. by super I/O
Power Supply
AT/ATX supported
Temperature
0ºC – 60ºC (32ºF - 140ºF)
Humidity (operating)
5%~95% non-condensing
Dimensions (LxW)
338.58 mm x 121.92 mm
Weight (GW/NW)
1100g/ 380g
