WSB-9152 PICMG 1.0 SBC
Page 5
 2 x IDE disk drive connectors
 1 x Infrared connector
 1 x Keyboard connector
 1 x LVDS connector
 1 x Inverter connector
 1 x Parallel port connector
 1 x PCIe mini card connector
 4 x Serial ATA (SATA) connectors
 2 x Serial port connectors
 1 x S-Video connector
 6 x USB connectors
The WSB-9152 has the following external peripheral interface connectors on the board
rear panel
 2 x Ethernet connectors
 1 x Keyboard/Mouse connector
 1 x USB port connector
 1 x VGA connector
The WSB-9152 has the following on-board jumpers:
 Clear CMOS
 FSB frequency selector
 LVDS voltage selector
1.2.3 Technical Specifications
WSB-9152 technical specifications are listed in Table 1-2. See Chapter 2 for details.
Specification WSB-9152
Form Factor
PICMG 1.0
System CPU
Intel® Pentium® M
Intel® Celeron® M
Front Side Bus
400 MHz or 533 MHz
