IEI Technology WSB-9152 - 2.4 Compatible Processors

WSB-9152 PICMG 1.0 SBC
Page 12
2.4 Compatible Processors
2.4.1 Compatible Processor Overview
Figure 2-4: Socket 479
The WSB-9152 supports the following socket 479 processors:
 Intel® Pentium® M processors
 Intel® Celeron® M processors
All the above processors communicate with the Intel®
915GME Northbridge chipset
through a 533 MHz or 400 MHz front side bus (FSB). Compatible processors are listed in
Table 1-2.
Family CPU Speed Processor # Bus Speed Mfg Tech Cache Size
Pentium® M 2.26 GHz 780 533 MHz 90 nm 2 MB L2
2.13 GHz 770 533 MHz 90 nm 2 MB L2
2.10 GHz 765 400 MHz 90 nm 2 MB L2
2 GHz 760 533 MHz 90 nm 2 MB L2
2 GHz 755 400 MHz 90 nm 2 MB L2
1.86 GHz 750 533 MHz 90 nm 2 MB L2
1.80 GHz 745 400 MHz 90 nm 2 MB L2
1.73 GHz 740 533 MHz 90 nm 2 MB L2
1.70 GHz 735 400 MHz 90 nm 2 MB L2
