WSB-9152 PICMG 1.0 SBC
Page 59
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
17 LVDSB_Y1+ 18 LVDSB_Y1-
19 LVDSB_Y2+ 20 LVDSB_Y2-
21 LVDSB_CLK+ 22 LVDSB_CLK-
23 N/C 24 N/C
25 GROUND 26 GROUND
27 VCC_LVDS 28 VCC_LVDS
29 VCC_LVDS 30 VCC_LVDS
Table 4-14: LVDS LCD Port Connector Pinouts
4.2.13 Parallel Port Connector
CN Label: LPT1
CN Type:
26-pin box header
CN Location:
See
Figure 4-14
CN Pinouts:
See
Table 4-15
The 26-pin parallel port connector connects to a parallel port connector interface or some
other parallel port device such as a printer.
