IEI Technology WSB-9152 - Fan Connector (+12 V, 4-Pin); Figure 4-4: Backplane to Mainboard Connector Location; Table 4-5: Backplane to Mainboard Connector Pinouts

WSB-9152 PICMG 1.0 SBC
Page 46
Figure 4-4: Backplane to Mainboard Connector Location
PIN NO. DESCRIPTION
1 GND
2 PS_ON#
3 5 VSB
Table 4-5: Backplane to Mainboard Connector Pinouts
4.2.4 Fan Connector (+12 V, 4-pin)
CN Label: CPU_FAN1
CN Type:
4-pin header
CN Location:
See
Figure 4-5
CN Pinouts:
See
Table 4-6
