4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the WSB-9152.
4.2.1 Audio Connector (9-pin)
CN Label: J_AUDIO1
CN Type:
9-pin header
CN Location:
See
Figure 4-2
CN Pinouts:
See
Table 4-3
The 9-pin audio connector is connected to external audio devices including speakers and
microphones for the input and output of audio signals to and from the system.
Figure 4-2: Audio Connector Location (9-pin)
