WSB-9152 PICMG 1.0 SBC
Page 32
2.9.1 IEI Expansion PCI/PX Backplanes
The backplanes listed in Table 2-4 are compatible with the WSB-9152 and can be used to
develop highly integrated industrial applications. All of the backplanes listed below have
24-pin ATX connector and a 4-pin ATX connector. For more information about these
backplanes please consult the IEI catalog or contact your vendor, reseller or the IEI sales
team at
sales@iei.com.tw.
Model
Total
Slots
PCI Slots ISA Slots
PCI-4S-RS-R31 4 3 1
PCI-5S-RS-R31 5 3 2
PCI-5S2 A-R10
PCI-5S2 A-R30
5 4 1
PCI-6S-RS-R31 6 4 2
PCI-7S-RS-R30 7 4 3
PCI-8S-RS-R30 8 4 4
PX-8S-RS-R30 8 6 2
PCI-10S-RS-R30 10 4 5
PX-10S-RS-R30 10 7 3
PCI-10S2-RS-R30 10 4 5
PCI-12S-RS-R30 12 4 7
PCI-13SD-RS-R30 13 3+4 3+3
PCI-14S-RS-R30 14 4 9
PCI-14S2-RS-R31 14 4 8
PCI-14S3-RS-R30 14 4 9
PX-18SQ-RS- R30 18 12 2
PX-14S2-RS-R30 14 7 6
PX-14S3-RS-R30 14 12 2
PX-14S5-RS-R30 14 7 6
PCI-19S-RS-R30 19 4 14
PX-20S2-RS-R31 20 17 3
PX-20S3-RS-R31 20 18 1
PCI-2SD2-RS-R30 2 R2
