IEI Technology WSB-9152 - IEI Chassis; Table 2-4: Compatible IEI Picoe Backplanes

WSB-9152 PICMG 1.0 SBC
Page 33
Model
Total
Slots
PCI Slots ISA Slots
PCI-5SD5-RS-R30 6 L2 + R2
PCI-5SD6-RS-R30 6 L2 + R2
PCI-5SDA-RS-R30 6 L2 + R2
PCI-6SD-RS-R30 6 L1 + R1 L1 + R1
Table 2-4: Compatible IEI PICOe Backplanes
2.9.2 IEI Chassis
IEI chassis available for WSB-9152 system development are listed in Table 2-5.
For more information about these chassis please consult the IEI catalog or contact your
vendor, reseller or the IEI sales team at
sales@iei.com.tw.
Model Slot SBC Mounting Max Slots Backplanes
PAC-42GF-R20 Full-size Wall 4 PCI-42-RS-R31
PAC-106G-R20 Full-size Wall 6 PCI-6S-RS-R31
PAC-107G-R20 Full-size Wall 6 PCI-6S-RS-R31
PAC-125G-R20 Full-size Wall 10 PCI-10S-RS-R30
PX-10S-RS-R30
PAC-1000G Full-size Wall 6 PCI-6S-RS-R31
RACK-220G 2U Rack 6 PCI-5SD5-RS-R30
PCI-5SD6-RS-R30
PCI-5SDA-RS-R30
PCI-6SD-RS-R30
RACK-305G-R20 4U Rack 14 PCI-13SD-RS-R30
PCI-14S2-RS-R31
PCI-14S3-RS-R30
PX-14S5-RS-R30
RACK-360G-R20 4U Rack 14 PCI-13SD-RS-R30
PCI-14S2-RS-R31
PCI-14S3-RS-R30
PX-14S5-RS-R30
