WSB-9152 PICMG 1.0 SBC
Page vi
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the WSB-9152 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to
sales@iei.com.tw.
The items listed below should all be included in the WSB-9152 package.
1 x WSB-9152 single board computer
1 x ATA 66/100 flat cable
2 x SATA cable (4 x SATA cable for WSB-9152S and WSB-9152SDVI)
1 x SATA power cable (2 x SATA power cable for WSB-9152S and
WSB-9152SDVI)
1 x KB/MS Y cable
1 x ATX-12 V cable
1 x RS-232 cable
1 x USB cable with bracket
1 x DVI cable (For WSB-9152DVI and WSB-9152SDVI only)
1 x IO-KIT-001-R20 (For WSB-9152DVI and WSB-9152SDVI only)
1 x Mini jumper pack
1 x Utility CD
1 x QIG (quick installation guide)
Images of the above items are shown in Chapter 3.
