2 - TECHNICAL INFORMATION Master 80 UP HyperFlexible
2 - Pag. 22 / 22
General technical data
MASTER 80 UP HyperFlex
Round bar size
Ø Min 8 mm
(5/16")
Ø Max 80 mm
(3")
Hexagonal bar size (key socket)
Min7 mm
(5/16")
Max65 mm
(2" 1/4)
Square bar side
Min7 mm
(5/16")
Max50 mm
(2")
Minimum bar length
Ver.33 – 1500 mm (4,9 ft)
Ver.38 – 2000 mm (6,5 ft)
Ver.43 – 2000 mm (6,5 ft)
Maximum bar length
Ver.33 – 3300 mm (10,8 ft)
Ver.38 – 3800 mm (12,4 ft)
Ver.43 – 4300 mm (14,1 ft)
Magazine capacity (working width)
600mm
(ex:n?60 bars of ø 10mm) (ex:n?7
bars of ø 80mm)
Maximum bar weight
120 kg
(Adjustable) feeding speed
150 mm/sec
(Adjustable) return speed
950 mm/sec
Maximum remnant length
ø 8÷65 mm = 400 mm
ø 66÷80 mm = 250 mm
Minimum remnant length
110 mm
Bar change time (with 3,000 mm bar)
40 sec (according to the bar ø)
Power supply voltage
230/400 Volt
Mains frequency
50/60 Hz
Control voltage
24 Volt A.C. - 24 Volt D.C.
Installed power
3 kW
Oil quantity
80 l
Air pressure
6 bar
Air consumption
35 Nl/bar change
Bar feeder weight
Ver.33 - 1500 kg
Ver.38 - 1600 kg
Ver.43 - 1700 kg
Electric cabinet weight
140 kg
