2 - TECHNICAL INFORMATION Master 80 UP HyperFlexible
2 - Pag. 24 / 24
Guide channel, bar pusher, bar and pipe diameter.
Model
Guide
channel
diameter(mm
)
Bar pusher
diameter(m
m)
Bar diameter(mm)
Pipe
diameter(m
m) (*)
Minimum Maximum
MASTER 80 UP
HyperFlex
21 20 8 18 20
26 25 8 23 25
33 32 10 29 31
36 35 10 32 35
38 37 11 35 37
43 42 12 39 42
46 45 15 42 45
52 51 (**) 15/20 47 51
57 56 (**) 15/20 52 55
61 60 (**) 15/20 56 59
66 65 (**) 15/20 61 64
69 68 (**) 15/20 63 67
71 70 (**) 15/20 65 69
73 72 (**) 15/20 67 71
76 75 (**) 15/20 70 74
81 80 (**) 15/20 75 79
86 85 (**) 15/20 80 80
(*) Valid also for prepared bars or normal bars machined with front remnant ejection.
(**) Ø 20mm brass.
WARNING - CAUTION:
the collet external diameter should be at least 0.5 mm smaller than the bar
pusher external diameter.
