5 - ADJUSTMENT AND SETUP Master 80 UP HyperFlexible
5 - Pag. 8 / 8
• Remove the screw (E), lower the
rear lever and move the bar
feeder body backwards.
WARNING - CAUTION:
before performing this
operation, power the lathe
off.
• Remove the oil recovery device (C) and sleeve
(D).
• Lower spring (G) and remove cover (F),
completely open the two half-bushings by
manually turning shaft (E) and remove the lower
half-bushing.
• Close the upper half-bushing by turning the shaft
again then replace it.
• Turn the shaft and fit the lower half-bushing.
• Close the half bushes completely and install the
cover.
E
A01PF_MUM_05_03_00
