5 - ADJUSTMENT AND SETUP Master 80 UP HyperFlexible
EN
5 - Pag. 9 / 9
• Remove the lathe spindle liner if required and
install a suitable liner for the "new" diameter, if
necessary.
• Assemble sleeve (D) of the "new" diameter and
the oil recovery (C).
• Move the bar feeder body
forwards and lift the rear lever,
turn screw (E) clockwise to block
the lever.
WARNING - CAUTION:
gradually bring the bar
feeder body up to the stop
placed on the tank, thereby eliminating the risk of damaging the displacement
device.
A01PF_MUM_05_03_01
E
