5 - ADJUSTMENT AND SETUP Master 80 UP HyperFlexible
EN
5 - Pag. 13 / 13
• Properly position the bar pusher in the radial
direction so that in the next phase of the upper
guide channel closing, the coupling between the
bar pusher and the first feeding carriage (B)
occurs correctly.
WARNING - CAUTION:
the above mentioned positioning has to
be always assured. Therefore during the
setup or maintenance operations, if the
bar pusher is struck involuntarily, it has
to be correctly repositioned.
• Press the start buttons together with to close the guide channels.
The machine is now ready to load the bar.
Perform a cycle in the "STEP by STEP" function.
INFORMATION:
Warning; follow the correct assembly direction of the guide channels.
