2. Press NAV to return to the Navigation
Mode.
3. Prior to reaching the IAF, determine if
sequencing is desired. Press OBS/HLD
and execute a procedure turn or holding
pattern entry if a course reversal
procedure is required.
4. If hold is selected after first crossing
the IAF, press DIRECT-TO twice.
Select your new inbound course to the
IAF with the Large and Small knobs.
When finished, press ENT.
5. Press OBS/HLD again to resume
sequencing and to continue your
approach when you have established an
inbound heading.
Final Approach Fix (FAF)
1. When you are 3 nm inbound to the
Final Approach Fix (FAF) and not on
Hold, the Active light will flash to
267
Operations Approach Operations
Approach Transition
peration
CDI Scale = 1.0nm
2nm to
FAF
3nm to
FAF
CDI Scale
Transitions
1.0 to 0.3nm
CDI Scale
Transitions
5.0 to 1.0nm
ACTIVE
Annunciator
Flashes
IAF
FAF
APPRCH Annunciator On
NAV
D D
ENT
