Emergency Mode Displays (continued)
Turning the Small knob clockwise displays all the nearest waypoints
in the database in sequence. Below is an example of the 5th closest
VOR.
NEAR 5 TO PPOS
BTG VOR
BRG 006° 61NM
The display below may be selected with the Large knob after entering
EMG mode, and is used to display the nearest SUAs (Special Use
Airspace areas). The top line shows the name of the SUA. The “2”
indicates this is the 2nd closest SUA to your position. The middle line
shows the type of SUA. “Inside” means you are inside of the SUA. The
bearing and distance to the nearest edge of the airspace is shown on the
bottom line. In this example, the second closest SUA to your position
is the Portland Oregon ARSA, and the nearest edge of the ARSA is
005
o
, and 6.2 nm.
PORTLAND OR 2
ARSA INSIDE
BRG 005° 6.2NM
The display below may be selected with the Large knob after entering
EMG mode, and is used to search around a waypoint. Pressing ENT
activates the Waypoint Retriever, allowing you to specify which
waypoint you want the system to search around.
CHOOSE WPT TO
SEARCH AROUND
PRESS ENT
28
Emergency Mode Displays Operations
