7.1 4K Format
151
UHK-430/CCU-430 1710 VER2 (E)
■
Output Form by Mode
Indicates the video processing system of the CCU implemented.
Depending on the availability of the optional module, the CCU output can be 4K only, HD only, 4K/HD simulcast, or HD double
speed/normal speed simulcast.
1 Plan A-1 (Standard configuration: HD mode)
- TRX_VP module is the HDTV (D/C) output mode.
- HD_VP module not implemented
  
HD OUT-1（D/C)
HD OUT-2（D/C)
4K Signal
TRX_VP Module
D/C
HD_VP Module
not implemented
SHAD,γ,MTX,
DTL,etc
SHAD,γ,MTX,
DTL,etc
Camera output CCU video processing Video signal output
2 Plan A-2 (Standard configuration: 4K mode)
- TRX_VP module is the 4K output mode.
- HD_VP module not implemented

  
4K QL OUT-1
（2SI or SQD)
4K QL OUT-2
（2SI or SQD)
Camera output CCU video processing Video signal output
4K Signal
HD_VP Module
not implemented
SHAD,γ,MTX,
DTL,etc
TRX_VP Module
