7.5 Video Signal Format Output
[SDI OUT-3, -4]
Indicates the video output signal format for the optional line system format.
IMAGE SIZE
FREQ &
SCAN
SAMPLING MAPPING 4K OUTPUT MON OUT SYNC OUTPUT
1920 x 1080
59.94P
YCbCr 422
3G SDI Level-
A/B
1080i59.94 422 HD-SDI 1080P59.94/1080i59.94
50P 1080i50 422 HD-SDI 1080P50/1080i50
59.94i
YCbCr 422 HD SDI
1080i59.94 422 HD-SDI 1080i59.94
50i 1080i50 422 HD-SDI 1080i50
59.94i
RGB 444
3G SDI Level-
A/B
1080i59.94 422 HD-SDI 1080i59.94
50i 1080i50 422 HD-SDI 1080i50
29.97P
YCbCr 422 HD SDI
1080P29.97 422 HD-SDI, or
1080P29.97sF 422 HD-SDI
1080P29.97/1080i59.94
25P
1080P25 422 HD-SDI, or
1080P25sF 422 HD-SDI
1080P25/1080i50
24P
1080P24 422 HD-SDI, or
1080P24sF 422 HD-SDI
1080P24/1080P24sF
23.98P
1080P23.98 422 HD-SDI, or
1080P23.98sF 422 HD-SDI
1080P23.98/1080P23.98sF
29.97P
RGB 444
3G SDI Level-
A/B
1080P29.97 422 HD-SDI, or
1080P29.97sF 422 HD-SDI
1080P29.97/1080i59.94
25P
1080P25 422 HD-SDI, or
1080P25sF 422 HD-SDI
1080P25/1080i50
24P
1080P24 422 HD-SDI, or
1080P24sF 422 HD-SDI
1080P24/1080P24sF
23.98P
1080P23.98 422 HD-SDI, or
1080P23.98sF 422 HD-SDI
1080P23.98/1080P23.98sF
29.97PsF
YCbCr 422 HD SDI
1080P29.97sF 422 HD-SDI 1080P29.97/1080i59.94
25PsF 1080P25sF 422 HD-SDI 1080P25/1080i50
24PsF 1080P24sF 422 HD-SDI 1080P24/1080P24sF
23.98PsF 1080P23.98sF 422 HD-SDI 1080P23.98/1080P23.98sF
29.97PsF
RGB 444
3G SDI Level-
A/B
1080P29.97sF 422 HD-SDI 1080P29.97/1080i59.94
25PsF 1080P25sF 422 HD-SDI 1080P25/1080i50
24PsF 1080P24sF 422 HD-SDI 1080P24/1080P24sF
23.98PsF 1080P23.98sF 422 HD-SDI 1080P23.98/1080P23.98sF
1280 x 720
59.94P
YCbCr 422 HD SDI
720P59.94 422 HD-SDI 720P59.94
50P 720P50 422 HD-SDI 720P50
Caution:
6RPHLWHPVPD\QRWEHRSHUDEOHGXHWR\RXURSHUDWLQJFRQ¿JXUDWLRQ
