Helpful Technical Information
7
163
UHK-430/CCU-430 1710 VER2 (E)
7.5 Video Signal Format Output
■
TRUNK VIDEO format is compatible with CCU output format settings
CCU OUTPUT FRAME /FIELD RATE Camera HD TRUNK IN
59.94 Progressive Interlace 1080I59.94 YCbCr 4:2:2 HD-SDI
1080P29.97sF YCbCr 4:2:2 HD-SDI
50 Progressive Interlace 1080I50 YCbCr 4:2:2 HD-SDI
1080P25sF YCbCr 4:2:2 HD-SDI
29.97 Progressive PsF 1080P29.97 YCbCr 4:2:2 HD-SDI
1080P29.97sF YCbCr 4:2:2 HD-SDI
25 Progressive PsF 1080P25 YCbCr 4:2:2 HD-SDI
1080P25sF YCbCr 4:2:2 HD-SDI
24 Progressive PsF 1080P24 YCbCr 4:2:2 HD-SDI
23.98 Progressive PsF 1080P23.98 YCbCr 4:2:2 HD-SDI
■
QTV/RETURN VIDEO format is compatible with CCU output format settings
CCU OUTPUT FRAME /FIELD RATE CCU HD QTV IN / RETURN IN
59.94 Progressive Interlace 1080P59.94 YCbCr 4:2:2 3G-SDI LVL-A/B
1080I59.94 RGB 4:4:4 3G-SDI LVL-A/B
1080I59.94 YCbCr 4:2:2 HD-SDI
50 Progressive Interlace 1080P50 YCbCr 4:2:2 3G-SDI LVL-A/B
1080I50 RGB 4:4:4 3G-SDI LVL-A/B
1080I50 YCbCr 4:2:2 HD-SDI
29.97 Progressive PsF 1080P29.97 RGB 4:4:4 3G-SDI LVL-A/B
1080P29.97sF RGB 4:4:4 3G-SDI LVL-A/B
1080P29.97 YCbCr 4:2:2 HD-SDI
1080P29.97sF YCbCr 4:2:2 HD-SDI
25 Progressive PsF 1080P25 RGB 4:4:4 3G-SDI LVL-A/B
1080P25sF RGB 4:4:4 3G-SDI LVL-A/B
1080P25 YCbCr 4:2:2 HD-SDI
1080P25sF YCbCr 4:2:2 HD-SDI
24 Progressive PsF 1080P24 RGB 4:4:4 3G-SDI LVL-A/B
1080P24sF RGB 4:4:4 3G-SDI LVL-A/B
1080P24 YCbCr 4:2:2 HD-SDI
1080P24sF YCbCr 4:2:2 HD-SDI
23.98 Progressive PsF 1080P23.98 RGB 4:4:4 3G-SDI LVL-A/B
11080P23.98sF RGB 4:4:4 3G-SDI LVL-A/B
1080P23.98 YCbCr 4:2:2 HD-SDI
1080P23.98sF YCbCr 4:2:2 HD-SDI
(YHQLI*6',VLJQDOVDUHLQSXWWHGWR&&8WKH4795(7851RXWSXWVRIWKHFDPHUDDUHFRQYHUWHGWR+'6',VLJQDOV
