8.1 Alarm Lamp on the OCP or MCP Flashes ON and OFF
200
UHK-430/CCU-430 1710 VER2 (E)
■
List of Self Diagnostic Information
7KHIROORZLQJWDEOHVOLVWWKHVHOIGLDJQRVWLFLQIRUPDWLRQIRUWKHVWDQGDUGVSHFL¿FDWLRQ
List of Self Diagnostic Information
Diagnosed Item Description Diagnosis Result Meaning
Camera Power Power status of the camera ON The camera is powered ON.
OFF The camera is powered OFF.
Camera Fan Rotating status of fan of the camera AUTO SSLOW Super-slow in auto mode
AUTO SLOW Slow in auto mode
AUTO NOR Normal in auto mode
AUTO FAST Fast in auto mode
FAST Fast in manual mode
NG Fan has stop.
Camera Temp Internal temperature of the camera OK Normal
NG The internal temperature is abnormally.
Camera Battery Status of the battery in the MPROC
module of the camera
OK Normal
NG The backup battery voltage is low.
Camera Memory Status of the RAM in the MPU module
of the camera
OK Normal
NG Data in the module is abnormally.
CCU Fan Rotating status of the fans on the rear
and inside of the CCU
OK Normal
NG Internal cooling fan either has stopped.
CCU Temp Internal temperature of the CCU OK Normal
NG The internal temperature is abnormally.
CCU Battery Status of the battery in the CCU MPU
module and TRX_VP module
OK Normal
NG The backup battery voltage is low.
CCU Memory Status of the RAM in the CCU MPU
module and TRX_VP module
OK Normal
NG Data in the module is destroyed.
CCU >>>
Camera
(CCU to
Camera
transmission)
OPT Level Optical signal level sent from the CCU
to the camera (Detect the optical
receiving level at the camera side and
display the status).
OK Good
ATTEN The amount of light received decreased.
WARN The amount of light received significantly
decreased.
NG Light cannot be received.
SDI Status Monitors the data transmission status
between CCU and the camera.
OK Normal
NG Detect CRC error
Comm Status Status of the command signal sent
from the CCU to the camera
OK Normal
NG No command signals are sent, or a CPU error
occurs.
Camera >>>
CCU
(Camera
to CCU
transmission)
OPT Level Optical signal level sent from the
camera to the CCU (Detect the optical
receiving level at the CCU side and
display the status).
OK Good
ATTEN The amount of light received decreased.
WARN The amount of light received significantly
decreased.
NG Light cannot be received.
SDI Status Monitors the data transmission status
between CCU and the camera.
OK Normal
NG Detect CRC error
Comm Status Status of the command signal sent
from the camera to the CCU
OK Normal
NG No command signals are sent, or a CPU error
occurs.
