TROUBLE SHOOTING and MAINTENANCE
8
8.1 Alarm Lamp on the OCP or MCP Flashes ON and OFF
201
UHK-430/CCU-430 1710 VER2 (E)
Diagnosed Item Description Diagnosis Result Meaning
Cable Connection Optical fiber composite camera
cable connection status between the
camera and the CCU
OK Normal
OPEN Cable is not connected, or there is an open.
SHORT A short circuit occurs in the cable.
Safety signal Status of the safety signal sent from
the camera to the CCU
OK Normal
NG The safety signal is not received, or the
connected camera is not supported by this
CCU.
Camera ID Status of the model identification
signal sent from the camera to the
CCU
OK Normal
NG The model identification signal is not received,
or the connected camera is not supported by
this CCU.
Genlock Status of external SYNC signal INT No external SYNC signals are input (operation
is performed with internal SYNC signals.)
Internal mode
1080P59 When external SYNC signal is 1080P59.94
1080I59 When external SYNC signal is 1080i59.94
1080P23 When external SYNC signal is 1080P23.98
1080P23SF When external SYNC signal is 1080P23.98SF
1080P29 When external SYNC signal is 1080P29.97
720P59 When external SYNC signal is 720P59.94
1080P50 When external SYNC signal is 1080P50
1080P25 When external SYNC signal is 1080P25
1080I50 When external SYNC signal is 1080i50
720P50 When external SYNC signal is 720P50
UNKNOWN External synchronization signals have been
input, but cannot be identified.
Note:
V)VHJPHQWHG)UDPH
