Conversion of RANDOM Spectrum Data
1st. column 2nd. column 3rd. column
1st. line
Frequency[Hz] Data name 1[unit] Data name 2[unit] Data name 3[unit]
……
2nd. line ***.***, ***.***, ***.**, ***.**,
……
***.***, ***.***, ***.**, ***.**,
……
***.***, ***.***, ***.**, ***.**,
……
: : : :
：
***.***, ***.***, ***.***, ***.**,
……
・Fixed characters are written in Italic.
・Data name of graph is substituted for a data name.
・Unit of graph is substituted for a unit.
・Frequency data is substituted in the 1st. column.
・Spectrum data is substituted from the 2nd
.
column.
Conversion of SHOCK Waveform Data
・Fixed characters are written in Italic.
・Data name of graph is substituted for a data name.
・Unit of graph is substituted for a unit.
・Time data is substituted in the 1st. column.
・Each data is substituted from the 2nd
.
column.
1st. column 2nd. column 3rd. column
1st. line
Time[ms] Data name 1[unit] Data name 2[unit] Data name 3[unit]
……
2nd. line ***.***, ***.***, ***.**, ***.**,
……
***.***, ***.***, ***.**, ***.**,
……
***.***, ***.***, ***.**, ***.**,
……
: : : :
：
***.***, ***.***, ***.***, ***.**,
……
