IMV K2 - Precautions for ‘Standards’ Mode and ‘Test Files’ Mode

7 - 2
7.1.1 Precautions for ‘Standards’ Mode and ‘Test Files’ Mode
7.1.1.1 Preparation
In the ‘Standards’ and ‘Test files’ modes, test files are created with using the top information
registered in the excitation system information and input environment information. Be sure to
create excitation system information and input environment information before executing
the test.
For the creating procedures of excitation system information and input environment
information, refer to “Chapter 3 K2 System Setting”’.
7.1.1.2 Change of Excitation System Information
When changing the information of the excitation system to be used in the ‘Standards’ and
‘Test files’ modes, change the top information of the excitation system information.
7.1.1.3 Limit of Control Channel
In the ‘Standards’ and ‘Test files’ modes, the test with the control channel limited to 1ch is
executed.
When executing the test such as average value control, open test files from applications
and change the control channel setting. The modified test file can be executed in ‘Test files’
mode without changes.
Although test conditions based on the standards are input in advance in
‘Standards’ mode, they should be regarded as references only. When executing
test, be sure to refer to the standards, and fully check the test conditions.
