2 - 1
Chapter 2 System Set Up
2.1 Installation
Set up and instruction of I/O unit as a dedicated hardware for K2 system are described as below.
2.1.1 Environment for Installation
Note that the followings to set up the system ;
① Not to disturb the air for cooling the machine
Cooling fun of this machine are set on side panel.
Please do not disturb the cooling air by putting things around the machine.
② Avoid direct sunlight
③ Set the system in fresh air
Refer to “Chapter 1 System Configuration” about the detailed specification for the
consumption of electricity / environment of temperature.
2.1.2 Installation of K2 Interface Board
Be sure to discharge static electricity in your body by touching metal prior to work.
Turn off the power supply of the PC, and install the K2 PCI Express I/F board into the slot of the
PCI Express.
