2.1.3 Connection to PC
The PC and the K2 I/O Unit must be surely connected.
Type of bus PC I/O Unit
K2 dedicated
Bus
PC/AT K2 PCI Express
I/F Board (K2ST-34-011)
Bus input terminal on the back of K2 cabinet
IF IN (right side terminal）
or INTERFACE
2.1.4 Connection to Excitation System
① Input : Signal cables of each pickup set to the shaker are connected to input terminals of front
panel of the machine.
Please pay attention not to mistake the connection with pickups.
② Output : Output terminals of front panel of the machine and input terminal of the power
amplifier of the excitation system are connected by BNC cables.
Please pay attention not to mistake the connection with Power Amplifier.
