4 - 61
4.8.3 Contact I/O signal Setting
Input Part
Name Order
NOTUSE The specified terminal is not used.
RMTENB This item is for setting of an allowance of remote control for a contact state
before the initial measurement.
Valid : one time only before the initial measurement
Default : Remote control is always allowed.
SYSRDY This item is for setting of Excitation system to be available to operate.
Valid : in all the state of test operation mode
Default : Excitation system is always available to operate.
START This item is for starting of excitation, XFR measurement or data acquisition.
Valid : in the state of waiting for operation start, for XFR measurement start
or for data acquisition start
Default : no order
STOP This item is for stopping of excitation, XFR measurement or data
acquisition.
Valid : in the state of executing the operation, operating XFR measurement
or acquiring the data
Default : no order
PAUSE This item is for pausing of the excitation at ‘closed’.
And this item is for canceling the paused state and continuing the excitation
at ‘opened’.
Valid : the state in operation
Default : no order
Available software : SINE, RANDOM
DCAN This item is for canceling all input data and stopping the renewal operation
of control loop at ‘closed’. (for this result, checking operation such as
tolerance check are not executed.)
And this item is for canceling the valid state of this item and restarting the
loop renewal operation at ‘opened’.
Valid : the state in operation
Default : no order
Available software : RANDOM
UP This item is for increasing of the excitation level for the specified value in
Control Condition. (Note 1)
Valid : in the state of waiting for operation start or executing the test
operation
Default : no order
Available software : SINE, RANDOM
DOWN This item is for decreasing of the excitation level for the specified value in
Control Condition. (Note 1)
Valid : in the state of waiting for operation start or executing the test
operation
Default : no order
Available software : SINE, RANDOM
