5 - 2
SPOT
(*1)
Below buttons in the Manual operation tool bar are grayed out (invalidated):
“Excitation level up”, “Excitation level down”, “Excitation level change”,
“Shift to the beginning of the spot”, “Shift to the next spot”,
“Spot fixing”, “Spot fixing cancel”
(*1) If the initial excitation level is specified to under 0dB, there is no constraints in operation.
But a part of E-save functionality or whole functionality becomes invalid.
・Air-cooled systems：Blower control only
・Water-cooled systems：E-save functionality is invalid
5.2.2 Constraints in RANDOM
Common Prompt excitation in Retry excitation is invalidated.
The Excitation start option dialog which appears at the moment of Retry after
stopping the excitation once in the ordinary mode is changed to a message box to
select Yes/No of continuous excitation only.
E-save mode
E-save
mode
