4.2.6 Palette Operation
K2 application provides the function that the display space (a palette) of graphs and logs can
easily be moved or copied.
4.2.6.1 Palette Tool Icons
Commands used for handling pallets are indicated by icons on the lower part of graph
display area. When any icon is clicked, corresponding command is executed immediately.
Pallets are indicated split vertically. (Refer to “4.2.6.2 Moving the Palette”)
Positions of displayed some pallets are changed by turning them counterclockwise.
(Refer to “4.2.6.2 Moving the Palette”)
Positions of displayed some pallets are changed by turning them clockwise.
(Refer to “4.2.6.2 Moving the Palette”)
Deletes pallets.
Pallets are indicated split horizontally. (Refer to “4.2.6.2 Moving the Palette”)
Pallets are indicated split in a grid pattern. (Refer to “4.2.6.2 Moving the Palette”)
