4 - 62
Name Order
TRIG This item is for setting of external trigger.
Valid : in the state of waiting for external trigger ON
Default : no order
Available software : CAPTURE
NEXT This item is for proceeding to the next step (each process divided at the point
of a waiting state for the operator’s order is called ‘step’).
Valid : in the state of waiting for the order to proceed to the next step
Default : no order
Available software : SHOCK
RETRY This item is for preparing of excitation restart/reacquisition.
Valid : in the state of excitation finished.
Default : no order
NXLOOP This item is for renewing the drive data.
Valid : in the state of excitation finished.
Default : no order
Available software : SHOCK
EXIT This item is for exiting from test operation mode.
Valid : in the state of test operation mode except for in operation
Default : no order
XFRRNW This item is for renewing the XFR data.
Valid : in the state of excitation finished.
Default : no order
Available software : SHOCK
AUXIN1 This item is valid only when the application program defines signal
specification.
SINE : Sweep reverse (valid only in Sweep Test)
RANDOM : Sweep reverse (valid in SOR, ROR)
AUXIN2 Auxiliary output 2 : the same as in the above
SINE : Fixed sweep (Spot) / Cancel
(Valid only in Sweep Test, Spot Test).
RANDOM : Sweep reverse / Cancel (valid in SOR, ROR)
AUXIN3 Auxiliary output 3 : the same as in the above
SINE : Shift to the next spot (valid only in Spot Test)
AUXIN4 Auxiliary output 4 : the same as in the above
SINE : This item is for increasing of the excitation frequency for the
specified value in Operation Setting. (valid only in Manual Test)
(Note 2)
AUXIN5 Auxiliary output 4 : the same as in the above
SINE : This item is for decreasing of the excitation frequency for the
specified value in Operation Setting. (valid only in Manual Test)
(Note 2)
AUXIN6 Auxiliary output 6 : the same as in the above
SINE : Skipping to the beginning of the next sweep / Skipping to the first
spot
(Valid only in Sweep Test, Spot Test).
AUXIN7 Auxiliary output 7 : the same as in the above
