4 - 63
Name Order
AUXIN8 Auxiliary output 8 : the same as in the above
AUXIN9 Auxiliary output 9 : the same as in the above
AUXIN10 Auxiliary output 10 : the same as in the above
AUXIN11 Auxiliary output 11 : the same as in the above
AUXIN12 Auxiliary output 12 : the same as in the above
AUXIN13 Auxiliary output 13 : the same as in the above
AUXIN14 Auxiliary output 14 : the same as in the above
AUXIN15 Auxiliary output 15 : the same as in the above
AUXIN16 Auxiliary output 16 : the same as in the above
Name Order
Emergency stop This item is for operating of emergency stop. The mute function of D/A
converter decreases the drive output in hardware.
Note 1) Order signal must be a pulse keeping up more than about 500ms.
Excitation level is increased/decreased for the level specified in the application program by a
single pulse.
Pulses can be outputted continuously with having an interval of 500ms between each pulse.
Note 2) Order signal must be a pulse keeping up more than about 500ms.
Excitation frequency is increased/decreased for the level specified in the application program
by a single pulse.
Pulses can be outputted continuously with having an interval of 500ms between each pulse.
Note 3) When the same input contact signal is set to multiple input terminals, the operation is as
follows.
・AND condition (When all input contact signals are ON, the order is to be valid)
RMTENB, SYSRDY
・OR condition (When one of input contact signals is ON, the order is to be valid)
Contact input signal other than the listed above
