4 - 64
Output Part
Name Order
HOLDOFF The specified terminal is not used.
HOLDON The system is in Test Operation mode.
WSTART The system is in the state of waiting for excitation start, for XFR
measurement start or for acquisition start.
WTRIG The loop is to be ‘closed’ in the waiting state for the external trigger.
WNEXT This system is in the state of waiting for proceeding to the next step (each
process divided at the point of a waiting state for the operator’s order is
called ‘step’).
Available software : SHOCK
INMEAS The system is in XFR measurement.
(Initial measurement is not included.)
Available software : SHOCK
INOPE The system is in test operation or in data acquisition.
(Including the state in pause. However, the state in XFR measurement is not
included.)
SIGOUT The system is outputting the drive signal.
(Including the state in XFR measurement)
INPAUSE The system is in pause.
EXC0DB The system is operating the excitation at 0dB of excitation level.
TIMEUP Test operation is completed when the specified test time is passed.
(Finished normally)
FINISHED The system is in the state of excitation completion. (Including abort)
ABORTED The excitation is stopped by abort function.
ALARM The system is in the state of alarm detected.
Available software : SINE, RANDOM
CHKERR The excitation is stopped according to the result of Tolerance check as ‘NG’.
AUXOUT1 This item is valid only when the application program defines signal
specification.
Used in SCHEDULER (Amplifier ON).
AUXOUT2 Auxiliary output 2 : the same as in the above
Used in SCHEDULER (Amplifier OFF).
AUXOUT3 Auxiliary output 3 : the same as in the above
Used in SCHEDULER (X-axis).
AUXOUT4 Auxiliary output 4 : the same as in the above
Used in SCHEDULER (Y-axis).
AUXOUT5 Auxiliary output 5 : the same as in the above
Used in SCHEDULER (Z-axis).
AUXOUT6 Auxiliary output 6 : the same as in the above
SHOCK, BMAC : The contact output signal synchronized with contact input
signal ’ SYSRDY’. Used in driving simulator system.
AUXOUT7 Auxiliary output 7 : the same as in the above
AUXOUT8 Auxiliary output 8 : the same as in the above
AUXOUT9 Auxiliary output 9 : the same as in the above
