Intel 855GME User Manual

January 2007 51
Intel
®
855GME Chipset and Intel
®
6300ESB ICH Embedded Platform Design Guide
Intel
®
Pentium
®
M/Celeron
®
M Processor FSB Design and Power Delivery Guidelines
Data Group
2
D31# 564 HD31# 914
D30# 564 HD30# 464
D29# 564 HD29# 691
D28# 564 HD28# 768
D27# 564 HD27# 453
D26# 564 HD26# 815
D25# 564 HD25# 837
D24# 564 HD24# 493
D23# 564 HD23# 766
D22# 564 HD22# 731
D21# 564 HD21# 522
D20# 564 HD20# 714
D19# 564 HD19# 412
D18# 564 HD18# 834
D17# 564 HD17# 634
D16# 564 HD16# 593
DINV[1]# 564 DINV[1]# 628
DSTBP[1]# 564 HDSTBP[1]# 736
DSTBN[1]# 564 HDSTBN[1]# 787
Table 9. Intel
®
Pentium
®
M/Celeron
®
M Processor and GMCH Source Synchronous
FSB Signal Package Lengths (Sheet 2 of 6)
Signal
Group
CPU Signal
Name
Intel
®
Pentium
®
M/Celeron
®
M
Processor Package
Trace Length (mils)
GMCH Signal
Name
GMCH Package Trace
Length (mils)

Intel 855GME Specifications

General

Brand	Intel
Model	855GME
Category	Computer Hardware
Language	English
