855GME Chipset and Intel
®
6300ESB ICH Embedded Platform Design Guide
Intel
®
Pentium
®
M/Celeron
®
M Processor FSB Design and Power Delivery Guidelines
Data Group
3
D47# 661 HD47# 654
D46# 661 HD46# 647
D45# 661 HD45# 460
D44# 661 HD44# 563
D43# 661 HD43# 726
D42# 661 HD42# 828
D41# 661 HD41# 608
D40# 661 HD40# 358
D39# 661 HD39# 655
D38# 661 HD38# 619
D37# 661 HD37# 747
D36# 661 HD36# 633
D35# 661 HD35# 675
D34# 661 HD34# 683
D33# 661 HD33# 501
D32# 661 HD32# 664
DINV[2]# 661 DINV[2]# 784
DSTBP[2]# 661 HDSTBP[2]# 502
DSTBN[2]# 661 HDSTBN[2]# 538
Table 9. Intel
®
Pentium
®
M/Celeron
®
M Processor and GMCH Source Synchronous
FSB Signal Package Lengths (Sheet 3 of 6)
Signal
Group
CPU Signal
Name
Intel
®
Pentium
®
M/Celeron
®
M
Processor Package
Trace Length (mils)
GMCH Signal
Name
GMCH Package Trace
Length (mils)
