January 2007 53
Intel
®
855GME Chipset and Intel
®
6300ESB ICH Embedded Platform Design Guide
Intel
®
Pentium
®
M/Celeron
®
M Processor FSB Design and Power Delivery Guidelines
Data Group
4
D63# 758 HD63# 579
D62# 758 HD62# 509
D61# 758 HD61# 431
D60# 758 HD60# 522
D59# 758 HD59# 490
D58# 758 HD58# 347
D57# 758 HD57# 649
D56# 758 HD56# 372
D55# 758 HD55# 541
D54# 758 HD54# 598
D53# 758 HD53# 469
D52# 758 HD52# 575
D51# 758 HD51# 326
D50# 758 HD50# 549
D49# 758 HD49# 511
D48# 758 HD48# 372
DINV[3]# 758 DINV[3]# 431
DSTBP[3]# 758 HDSTBP[3]# 463
DSTBN[3]# 758 H DSTBN[3]# 505
Table 9. Intel
®
Pentium
®
M/Celeron
®
M Processor and GMCH Source Synchronous
FSB Signal Package Lengths (Sheet 4 of 6)
Signal
Group
CPU Signal
Name
Intel
®
Pentium
®
M/Celeron
®
M
Processor Package
Trace Length (mils)
GMCH Signal
Name
GMCH Package Trace
Length (mils)
