Intermec EasyCoder PC4 Programmer's Reference Manual

Appendix A — Error Handling
154 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
09 A Form or image not found GRN - 09<CRLF>
11 D Printhead up (cover open) RED [XOFF] 11<CRLF>
13 E LTS detection waiting, peel pause. - - 13<CRLF>
16 A No form was retrieved before
“?<CRLF>” was entered.
GRN - 16<CRLF>
17 C Out of ribbon, marked with Rnnn
= Number of remaining labels.
RED [XOFF] 17<CRLF>
50 A Does not fit in area specified. GRN - 50<CRLF>
51 A Data length too long GRN - 51<CRLF>
61 D High motor temperature BLNK
RED
[XOFF] 61<CRLF>
62 D High printhead temperature BLNK
RED
[XOFF] 62<CRLF>
71 F Wait after default setup. GRN [XOFF] 71<CRLF>
72 F Flashing not completed RED [XOFF] 72<CRLF>
73 F Download error RED [XOFF] 73<CRLF>
81 B Cutter jammed or not installed. BLNK
RED
[XOFF] 81<CRLF>
89 G Dump mode (after auto-
detection).
GRN - 89<CRLF>
92 H Pause printing mode BLNK
GRN/ORA
- 92<CRLF>
94 G Autosensing mode BLACK [XOFF] 94<CRLF>
98 G Download mode (not public use)
99 Other errors [XOFF] 99<CRLF>
Error Responses and Codes Reported When Command US Is Off (continued)
Error
Code
Error
Type Description LED Serial
Response to
Command ^ee

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
