Johnson Controls 100 Series User Manual

JOHNSON CONTROLS
22
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 2 – INSTALLATION
75 - 105 TON MODELS
MODEL SIZE 075 080 090 105
General Data
Standard cabinet length without hoods
(inches)
454 454 488 488
Extended cabinet length without hoods
(inches)
517 517 557 557
Width (Inches) 92 92 92 92
Height (Inches) 92 92 92 92
Weights (Lbs.) (base unit, no option)
Base cabinet, cooling only with
economizer
11,880 12,066 12,171 12,391
Extended cabinet, cooling only with
economizer
13,090 13,276 13,467 14,687
Option Weights (Lbs.)
Power Exhaust (Blower, mtr, mtr base, fan
skid, mod damper & hood)
1045 1045 1074 1074
Power Exhaust (Blower, mtr, mtr base, fan
skid, VFD,baro damper & hood)
1044 1044 1068 1068
100% AMS (Measurement Station &
Mounting)
125 125 140 140
25/75% AMS (Measurement Station &
Mounting)
146 146 162 162
Min. AMS (Measurement Station &
Mounting)
45 45 50 50
Barometric only 45 45 55 55
375 MBH Gas Heat 162 162 162 162
750 MBH Gas Heat 324 324 324 324
1050 MBH Gas Heat 486 486 486 486
40 kW/415/3/60 or 40 kW/480/3/60 2
Steps Electric Heat
NA NA NA NA
80 kW/208/3/60 or 108 kW/240/3/60 5
Steps Electric Heat
510 510 NA NA
108 kW/415/3/60 4 steps Electric Heat 470 470 510 510
150 kW/415/3/60 5 Steps Electric Heat 490 490 530 530
200 kW/415/3/60 or 200 kW/480/3/60 6
Steps Electric Heat
510 510 550 550
250 kW/480/3/60 7 Steps Electric Heat NA NA 570 570
Condenser Wire Guard 40 40 45 45
Copper Condenser Coils (additional) 617 1,058 1,190 1,190
Copper Evaporator Coils (additional) 460 280 460 580
Hot water coil 318 318 318 318
Steam heating coil 236 236 236 236
Diffuser
2
53 53 53 53
Final lters
2
535 535 565 565
Final lters, racks only
2
297 297 327 327
Roof Curb Weights (Lbs.)
14” Full Perimeter Roof Curb 1,020 1,020 1,040 1,040
TABLE 3 - PHYSICAL DATA (CONT'D)
