JOHNSON CONTROLS
23
SECTION 2 – INSTALLATION
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
2
75 - 105 TON MODELS
MODEL SIZE 075 080 090 105
14” Open Condenser Roof Curb 577 577 615 615
Compressor Data
Quantity/Size (Nominal HP) 4x11, 2x13 4x13, 2x11 2x13, 4x15 3x20, 3x15
Type Scroll Scroll Scroll Scroll
Capacity Steps (Qty x %) 6x16 4x16, 2x18 4x17, 2x15 3x14, 3x19
Refrigerant Charge (R-410A STD Cabinet)
SYS 1 - LB (KG) 38.0 38.0 41.5 45.4
SYS 2 - LB (KG) 32.4 35.3 32.0 39.6
SYS 3 - LB (KG) 33.0 33.0 36.2 45.4
Refrigerant Charge (R-410A EXTD Cabinet)
SYS 1 - LB (KG) 40.7 40.7 44.2 48.1
SYS 2 - LB (KG) 35.1 38.0 34.7 42.3
SYS 3 - LB (KG) 35.7 35.7 38.9 48.1
Supply Fan and Drive
Quantity 1 1 1 1
Type FC FC AF AF
Size 28-25 28-25 32 32
Motor Size Range (min. to max. HP) 10–50 10–50 10–50 10–50
Air Flow Range (min. to max. cfm) 15550–29000 15000–32000 17500–36000 21000–36000
Static Pressure Range (min. to max. ESP) 0–4” 0–4” 0–4” 0–4”
Optional Airfoil Supply Fan
Quantity 1 / 1 1 / 1 1 / 1 1 / 1
Type AF AF AF AF
Size 32 32 32 32
Motor Size Range (min. to max. HP) 15–50 15–50 15–50 15–50
Air Flow Range (min. to max. cfm) 15550–29000 15000–32000 17500–36000 21000–36000
Static Pressure Range (min. to max. ESP) 0–6” 0–6” 0–6” 0–6”
Optional Direct Drive Plenum (DDP) Supply Fan
Quantity 1 1 1 1
Type DDP DDP DDP DDP
Size 402-9-100/120 402-9-100/120 402-9-100/120 402-9-100/120
Motor Size Range (min. to max. HP) 10–75 10–75 10–75 10–75
Air Flow Range (min. to max. cfm) 15550–29000 15000–32000 17500–36000 21000–36000
Static Pressure Range (min. to max. ESP) 1–8” 1–8” 1–8” 1–8”
Exhaust Fan
Quantity 2 2 2 2
Type FC FC FC FC
Size 18-18 18-18 18-18 18-18
Motor Size Range (min. to max. HP) 10–20 10–20 10–20 10–20
Air Flow Range (min. to max. cfm) 40000-32000 40000-32000 40000-32000 40000-32000
TABLE 3 - PHYSICAL DATA (CONT'D)
