10
▋Using▋the▋transmitter▋and▋receiver.▋
Receiver▋mounting▋location.
▋▋Please▋set▋up▋the▋antenna▋direction▋as▋per▋the▋following▋drawing.
The 2.4GHz band radio waves are very directional. The receiver signal is very dependant on the direction
of the antenna. Since the antenna receives radio waves from the sides rather than from the tip, please
appropriately position the receiver antenna when installing the receiver in the model.
記号の意味
S
W
Weak radio wave
Radio wave is weak.
Strong radio wave
Strong radio wave transmitted
to the aircraft, helicopter, etc.
This position makes best transmission to the receiver
for those who fly Glider vertically and also those pilots
who holds the transmitter vertically to the aircrafts.
As the strong wave radiate from the sides of the
antenna, this makes the best transmission to the
receiver for those who fly Helicopter or the
Airplanes. Also suggested for those pilots who
hold the radio horizontally.
