76
âTransmitterâSettingăTXâSETTINGă
ââFunctionâExplanation
This function allows basic adjustment of transmitter settings such as LCD display mode, sound
(audio) mode, etc.
ââSettingâMethod
âż LCD Back light (BACK LIGHT)
The LCD Back light can be set to function in one of three modes.
1)î AUTO (Lit for 30 seconds & then automatically shuts oó±Ż)
2)î ON (Always on lit)
3)î OFF (Always oó±Ż)
âż LCD contrast (CONTRAST)
The LCD Contrast can be changed between numerical values of ± 20.
âż Idle Alert (ILDE ALERT)
This function ensures the operator does not forget to turn oó±Ż the transmitter. The idle (inactivity) time can be
set to four dió±Żerent settings.
INH / 10min / 30min / 60min
âż Low battery warning (LOW BATT.VOL)
This sets the voltage at which the Low battery alert triggers. Initially, it is set to 6.0V.
âż Audio Mode (SOUND MODE)
It is possible to change the audio pitch (or mute) for the following functions.
á§
Edit
á§
Trim step
á§
Side Lever Neutral center
á§
Timer sound
á§
Opening sound (Sound when the transmitter is î°rst turned on)
âż Stick Calibration (STICK CALIBRATION)
This function calibrates the neutral position of the stick and stick travel which is especially useful after
changing Stick modes ( Mode 1 to Mode 2 or Vice Versa). The calibration procedure is as follows.
â î Set both right and left sticks to their center positions, and press the function key to calibrate neutral.
âĄî Next move both right and left sticks up and down and right to left and press the Function key to calibrate stick
travels.
âąî Be sure to check control movement and neutral positions on the servo monitor screen.
âż Software version (SOFTWARE VER)
This indicates the current version of the transmitterâs software. For example: 0001-0000(Ver1.0)
