27
▋Throttle▋Curve【THRO▋CURVE】
▋▋Function▋Explanation
This function adjusts throttle servo operation in response to throttle stick operation. The servo
position can be set independently for a maximum of 7 point positions. In addition, an EXPO
(exponential) function is also incorporated to allow smooth throttle stick connection of each of
the points. This function is available in each Flight Mode for helicopters (maximum 5), and 2
modes for airplanes.
▋▋Setting▋Method
There are three initial curve points set at the slow, center, and high positions. To add a point, set the stick to
the desired position and press the “ADD” key. In the situation where a point is to be deleted, this should be
carried out using the “DEL” key. To change vales at each point, rotate the dial to move to and select the point
that you wish to change (inverse display). Then press the dial to select and change the numerical value.
▋▋For▋Helicopter
There are ve (5) ight modes (i.e. Normal, Stunt 1-4) available for helicopter throttle curves. Set each throttle
curve as desired for the particular ight condition.
Adjusting point Display
Current Flight Mode position
Point addition and deletion
This changes the point connections to a Curve.
Numerical Display of the
Stick input Position and
output position
Adjusting point Display
Current Flight Mode position
Point addition and deletion This changes the point connections to a Curve.
Numerical Display of the
Stick input Position and
output position
Each Adjusting point input
Position and output position
Copy function
To Next Page
