JR XG 14 User Manual

20
▋▋Glider▋ight▋mode
▲ SPEED
▲ CRUISE
▲ THERMAL
△ LAND
△ LAUNCH
▽ DIST
▽ ZOOM
▽ FREE
※ Glider flight modes are not activated by default.
It is possible to activate these ight modes in the
system list, "DEVICE SELECT".
※ By setting the “SPEED” it is possible to utilize ▲
marked mode which are CRUISE and THERMAL.
※ If require to have further ight mode, select “LAUNCH”.
Depending on selecting the type of the toggle switch, certain ight mode is selectable.
3position switch: Those ight mode which marked with △
2position switch: Only with “LAUNCH” mode is selectable.
ThoseFlightmodewhichmarkedwiththis▽canbeselectableuponcustomizedonFlightmode.
※ The following sequence gives the ight mode priority when the various switches are activated.
"LAUNCH>SPEED/THERMAL>LAND>CRUISE"
▋▋Example▋List▋of▋the▋items▋which▋can▋be▋selected▋on▋each▋ight▋mode
Functions which can be modified on each flight mode are digital trims, and settings related to the following
functions:
Note:
Each type of aircraft (heli, airplane or glider) uses a di󱐯erent name for each ight mode.
Other function that can be modied in each ight mode are for example.
፧
DUAL-RATE & EXPONENTIAL【D/R&EXP】 .........Page 21
፧
Servo Speed【SERVO SPEED 】 ....................................Page 26
፧
Di󱐯erential【DIFFERENTIAL】 .....................................Page 41
፧
Throttle Curve【THRO CURVE】 ................................. Page 27
፧
Pitch Curve【PITCH CURVE】 ......................................Page 29
፧
Tail Curve【TAIL CURVE】 .............................................Page 30
፧
Gyro Sensitivity【GYRO SENS】 ...................................Page 32
፧
Governor【GOVERNOR】 ................................................Page 34
፧
Mixing Functions
፧
and more
Current Flight Mode
Current Flight Mode
