3─36
3
3.5 BASIC OPERATIONS
y
y y
Parallel Index Line
1. Display
ON
2. Range Link
OFF
3. PI Bearing REF
RUE
4. PI Floating
OFF
5. PI Bearing Fix
SCREEN
6. PI Individual
PI Bearing
Interval
0. EXIT
1.00
000.0
[III] Parallel Index Line Bearing (PI Bearing REF)
Parallel index line bearing mode can be switched.
Procedures 1 Press [RADAR MENU] key twice.
Press [3] key.
Press [5] key.
The Parallel Index Line Menu will appear.
2 Press [3] key.
The PI Bearing REF mode is switched between
true bearing and relative bearing each time you
press [3] key.
* PI bearing in the parallel index line menu will show which is
selected, true bearing or relative bearing.
℃
nm
