3─79
3 Correcting a continuous line or moving a mark (Correct)
Procedures 1 Press [3] key while the Edit User Map Menu is open.
The navigation information correction mode will be activated.
Correct will appear in the CURSOR mode field at the radar display button
19
.
2 Use the trackball to move the pointer to the vertex in a line to be
corrected or the mark to be moved, and press [ENT] key.
The cross cursor mark will appear on the selected line or mark.
3 Use the trackball to move the cross cursor mark to a new point to which
the line is corrected or the mark is moved.
The selected line will be corrected to the new point, or the mark will be moved there.
4 To correct another line or mark, repeat steps 2 and 3.
5 Press [0] key when finishing the correction of lines and marks.
The CURSOR mode at the upper right of the radar display will change to the general
operation mode, terminating the navigation information correction mode.
(Example)
Select a top
