8─5
Sensor Test
OK
※ Safety Switch
0. EXIT
OK
※ AZI Pulse
OK
※ HL Pulse
OK
※ MH Current
OK
※ Trigger
OK
※ Video
2) Sensor Test
Checks for signals from the antenna.
Safety Switch
Antenna’s safety switch check
AZI Pulse
Antenna rotation signal check
HL Pulse
Heading line signal check
MH Current
Check on the load current of high voltage in the modulator
Trigger
Radar trigger signal check
Video
Radar video check
Procedures 1 Press [2] key while the Self Test menu
is open.
The Sensor Test menu will appear.
When no abnormality is found, OK is
displayed.
When an abnormality is found, NG is
displayed.
In standby, ** will appear.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
