8.5 Adjustments
yyyy
yyyy
8
Bearing Pulse Output Adjustment (Output Pulse)
Set the output value of bearing pulse. This radar can set the output value to 2048 pulses and 4096 pulses.
This setting is allowed only when a 25 kw antenna is used.
Procedures 1 Open the Equipment Setup Menu.
2 Press [4] key.
The TRX Setting Menu will appear.
3 Press [7] key.
4 Select a set value to be used.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
T
RX Setting
1. Anntena Height
5-10m
2.
T
une Peak Adjust
0
0
8.Antenna Location
0. EXIT
3.
T
une Indicator Adjust
0
4. PM Adjustment
5.Manual Tune Adjustment
2048
7. Output Pulse
0m0m
