1 - 3
Improved Day/Night Mode
Two types of background colors are available in each Day/Night mode (total 4 background colors).
Each background color can be reproduced to be suited for the user’s operating environment by simple key
operation. The radar echoes and a variety of graphics can also be represented in different colors, ensuring
easy-to-see displays.
Compact Design and Low Power Consumption
Since an LCD has been implemented as the display device, the weight of the display is greatly reduced and the
power consumption is lowered in comparison with the conventional radar equipment.
Self-diagnostic Program Incorporated
The Self-diagnostic program always monitors all the functions of the system. If any function deteriorates, an
alarm message will appear on the radar display and an alarm sounds at the same time. Even when the system
is operating, the functionality test can be carried out. (except on some functions)
Performance Monitor (Option)
The radar performance (transmitted output power and receiving sensitivity) can appear on the radar display.
* The PM unit (NJU-64) is needed separately.
Simplified Inter-switch Operation (Option)
If an simplified inter-switch unit (option) is installed, up to two JMA-5200 radars can be switched over by
performing simple operation.
* An simplified inter-switch option is required separately.
Various Functions
• RADAR TRAILS (Other ship’s track display)
• TM (True Motion) display
• Head-up/North-up/Course-up display
• Own ship’s track display
• Guard Zone function
