JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.3 OPERATION PROCEDURES
3ļ¼17
3
3.3.3.7 Menu Operation with the Trackball
3.3.4 Operation on Numeric Value, Latitude / Longitude and
Character Input menu
When a numeric value must be entered while operating this radar system, the
numeric value input screen will appear. In that case, enter a numeric value
according to the following operation method.
Press numeric keys
corresponding to the desired
item number to display the
selected item.
Press numeric keys
corresponding to the
desired item number to
select a set value.
Software button
Press the
[0]
key to
move to the higher level.
When the [ > ] mark appears
at the right end of a menu
item, press numeric keys
corresponding to the selected
item number to move to a
lower level.
Item
Selected item
Cursor
Present state
To Next Page
